Graphic Displays


	If you were using a Java-enabled browser, you would see an amazing animated graphic display instead of this paragraph.

Dynamic are pleased to announce the launch of their NEW hi-tech range of full animation graphic displays - DYNAVISION. These fantastic displays are designed for high-impact promotions in outdoor and large scale indoor situations.

DynaVision - The Greatest Graphics Display

DynaVision - The Greatest Graphics Display

A pair of 3m x 250mm DynaVisions installed at a Theatre/Cinema. Displays have either 1 line of 16 x 250mm characters or 2 lines of 32 x 100mm characters. Can also show graphics (supplied via Jayex)

Graphic Displays

A DynaVision used to give employees safety information, including a countdown in seconds to a new safety directive (supplied via LED Systems)

Graphic Displays

One of the DV1 range DynaVision installed on a military base. 2500mm x 250mm. 160 x 32 pixels. (supplied via Esprit)

Graphic Displays

A DV4 range DynaVision for supplying information to queuing Ferry Passengers. Also integrates into the ferry companies time table system to automatically show the next sailing time. Overall size approx. 3.1m x 1.1m (supplied via Jayex)

General Specifications
Display Features:	Display of bitmap animations with 24 effects. Use of any windows font at any size.
Keyboard Control Option:	Simple Infra-red remote control allows access to basic functions
Computer Control Option:	Powerful, easy to use Windows software. Choice of RS232, RS485, Modem or GSM (cellular) link. Up to 256 displays in each network segment.
Message Memory Size:	Basic: 256K expandable to 4M
Message Retention:	3 years without power.
Case construction:	Weatherproof anodised aluminium extrusion body Anti-glare Acrylic/Polycarbonate fascia Suitable for wall/post mounting / hanging.
Power:	230 / 110 V AC operation Internal power supply Waterproof mains inlet Supplied with 2m flex and fitted plug.
Operating conditions:	-20°C to 50°C ambient temperature 0°F to 120°F ambient temperature 0 to 90% humidity (non-condensing)

DynaVision is currently available in two pixel pitches; 15mm (0.6") and 30mm (1.2").

The 15mm pitch display has one LED per pixel and is great for indoor and close-quarter outdoor situations or where high resolution is important.

The 30mm pitch display is available in both single and tri-colour configurations, 4 LEDs per pixel are used for single-colour operation and 9 pixels in tri-colour mode. This display is most suited to long-range viewing.

The size of any DynaVision can be user specified in steps of approx. 250mm (10") in both height and width. The following tables give some popular configurations.

15mm (0.6") pitch pixels
Model	Case	Resolution	Characters (small fonts)	Power	Weight
DV1-4/1	1060mm Wide 330mm High 70mm deep	64 x 16	10 characters 2 lines	100W Max	5Kg
DV1-8/1	2035mm Wide 330mm High 70mm deep	128 x 16	21 characters 2 lines	200W Max	9Kg
DV1-4/2	1060mm Wide 580mm High 70mm deep	64 x 32	10 characters 4 lines	200W Max	9Kg
DV1-6/2	1550mm Wide 580mm High 70mm deep	96 x 32	16 characters 4 lines	310W Max	13Kg
DV1-6/4	1550mm Wide 1060mm High 70mm deep	96 x 64	16 characters 8 lines	620W Max	25Kg
DV1-8/4	2040mm Wide 1060mm High 70mm deep	128 x 64	21 characters 8 lines	820W Max	33Kg
DV1-12/6	3010mm Wide 1550mm High 70mm deep	192 x 96	32 characters 12 lines	1850W Max	74Kg

For other configurations or imperial measurements please contact us.

30mm (1.2") pitch pixels
Model	Case	Resolution	Characters (small fonts)	Power	Weight
DV4-8/2	2020mm Wide 560mm High 70mm deep	64 x 16	10 characters 2 lines	250W Max	17Kg
DV4-16/2	3970mm Wide 560mm High 70mm deep	128 x 16	21 characters 2 lines	500W Max	33Kg
DV4-24/2	5930mm Wide 560mm High 70mm deep	192 x 16	32 characters 2 lines	740W Max	50Kg
DV4-8/4	2020mm Wide 1050mm High 70mm deep	64 x 32	10 characters 4 lines	500W Max	33Kg
DV4-12/4	3000mm Wide 1050mm High 70mm deep	96 x 32	16 characters 4 lines	740W Max	50Kg
DV4-12/8	3000mm Wide 2020mm High 70mm deep	96 x 64	16 characters 8 lines	1475W Max	99Kg
DV4-16/8	3970mm Wide 2020mm High 70mm deep	128 x 64	21 characters 8 lines	1970W Max	132Kg
DV4-24/12	5930mm Wide 3000mm High 70mm deep	192 x 96	32 characters 12 lines	4425W Max	295Kg

For other configurations or imperial measurements please contact us.
